RHG6 Turbocharger for Sumitomo SH200-3 Excavator With Isuzu 6BG1T Engine
Compatible Part Numbers:
VA570019 VB570019 VC570019 VD570019 1144003890 1-14400-3890 114400-3890
The RHG6 Turbocharger is engineered as a direct replacement for Sumitomo SH200-3 excavators equipped with the Isuzu 6BG1T engine. Designed for harsh, continuous construction environments, this turbo delivers stable boost, stronger torque, and long-lasting performance under high-load operations.
If your SH200-3 is experiencing power loss, slow hydraulic response, smoke, or turbo noise — this is the OEM-standard solution that brings your machine back to peak performance.
Key Features & Advantages
OEM-Standard Fit & Performance
Perfect replacement for the original IHI RHG6 turbo, following exact factory dimensions and tolerance requirements.
High-Temperature Turbine Material
Turbine housing made from Ni-resist alloy for exceptional heat resistance during long excavation cycles.
Heavy-Duty Journal Bearings
Enhanced bearing life ensures stable boost even during continuous 10+ hour operation.
Precision Dynamic Balancing
CHRA balanced to over 150,000 RPM, eliminating vibration, noise, and premature failure.
Fast Boost Response
Optimized compressor wheel design improves throttle reaction, digging force, and overall efficiency on the jobsite.
Long Service Life
Designed for dust, high load, and heavy hydraulic-duty cycles typical of excavator applications.
Who Is This Turbocharger Designed For?
This product is perfect for:
-
Sumitomo SH200-3 excavator owners
-
Construction companies managing fleets
-
Repair workshops & machinery rebuilders
-
Heavy equipment rental companies
-
Distributors of Isuzu 6BG1T engine parts
If your machine needs reliable boost, lower downtime, and longer engine life, this is the solution.
What Problems Does This Turbo Solve?
Loss of digging force & slow hydraulic speed
Restores boost to maintain full engine torque.
Excessive black smoke
Improves air–fuel mixture for cleaner combustion.
Turbo whistling, grinding, or oil leakage
Precision balancing and new seals eliminate common failure symptoms.
High fuel consumption
Proper turbo efficiency reduces unnecessary fuel burn.
Overheating during continuous work
Better airflow reduces thermal stress on the engine.
Technical Specifications
| Turbo | Details |
|---|---|
| Model | RHG6 Turbocharger |
| OEM Numbers | VA570019 VB570019 VC570019 VD570019 1144003890 1-14400-3890 114400-3890 |
| Engine | Isuzu 6BG1T Engine |
| Machine Model | Sumitomo SH200-3 |
| Bearing Type | Journal bearing |
| Cooling | Oil-cooled |
| Material | High-nickel turbine housing / aluminum compressor wheel |
| Fitment | 100% OEM-compatible direct replacement |
Application Scenarios
- Earthmoving & excavation
- Mining and quarry operations
- Construction job sites
- Road building
- Heavy-duty rental machinery
- Long-hour industrial operations
Your excavator returns to strong, consistent power output — even under harsh and dusty conditions.
Installation Guide (Step-by-Step)
1. Pre-installation Checks
- Flush engine oil & replace filter
- Check oil feed/return lines for blockage
- Inspect air filter & intake pipes
- Ensure no debris remains in the exhaust manifold
2. Turbo Installation Steps
- Remove old turbo and clean mounting surfaces
- Install new gaskets and fit the RHG6 turbo
- Connect oil feed & return lines
- Tighten bolts according to OEM torque specs
- Fill turbo oil inlet with clean engine oil (priming)
- Start engine and idle for 3–5 minutes
- Inspect for oil, air, or exhaust leaks
3. Break-in Procedure
Avoid full load for the first 15–20 minutes to allow oil circulation.
Troubleshooting Guide
| Issue | Possible Cause | Recommended Solution |
|---|---|---|
| Black smoke | Low boost | Check intercooler & pipes |
| Whistling sound | Air leakage | Tighten clamps / replace hoses |
| Oil leakage | Blocked return line | Clean or replace line |
| Slow spool | Exhaust leak | Inspect manifold gasket |
| Vibration | Poor oil quality | Replace oil & filter |
FAQ
Q1: Is this turbo an OEM or aftermarket product?
A: It is an OEM-standard aftermarket replacement, built to the same performance and durability requirements as IHI factory turbos.
Q2: Do you supply complete kits?
Yes — CHRA, repair kits, shafts, wheels, and housings are all available.
Q3: Can this turbo be used on other machines with 6BG1T engines?
Yes, as long as the OEM part numbers match.
Q4: What is the warranty?
12-month warranty covering manufacturing defects.
Q5: Do you support bulk orders?
Yes — we support wholesale, OEM branding, and distributor pricing.
