RHG8V Turbo CHRA VE520040 24100-4223 S1760-E0040 Turbocharger Cartridge for Hino E13CT Engine

RHG8V Turbo CHRA VE520040 24100-4223 for Hino E13CT 700 Engine

Product Overview

Stop oil burning and restore heavy-hauling power to your Hino 700 Series. Drop-in RHG8V replacement turbo CHRA for E13CT engines (OEM 24100-4223). VSR balanced. ISO/IATF certified factory direct.

Premium RHG8V Turbocharger CHRA for Hino E13C-T (12.9L) Heavy-Duty Engines

• Cost-Effective Repair Solution: Avoid the massive expense of a complete turbocharger replacement. This precision-engineered CHRA (Cartridge) is a 1:1 direct replacement for your Hino 700 Series E13C engine, restoring factory boost levels at a fraction of the OEM cost.
• VGS/VGT Synchronization: Specifically designed to work with the RHG8V's Variable Geometry System. The turbine wheel and shaft dimensions are precision-matched to ensure zero interference with the variable nozzle ring mechanism.
• K18 Nickel-Alloy Turbine Wheel: Features a high-grade K18 Nickel-Alloy turbine wheel, capable of withstanding the extreme exhaust temperatures (up to 950°C) generated by a 13-liter heavy-duty engine under full load.
• Precision VSR Balancing: Every CHRA is 100% dynamic balancing tested on a Vibration Sorting Rig (VSR) at high speeds (up to 150,000 RPM). Technical Benefit: This eliminates vibration, reduces bearing noise, and ensures a service life of 500,000+ kilometers.
• Ready-to-Install: Fully assembled and balanced at the factory. Includes a quality control certificate and a basic gasket kit to ensure a clean, leak-free installation.

Technical Specifications & OEM Cross-Reference

Applications

• Hino 700 Series: Heavy-duty logistics and construction trucks (FS, FY, SH models).
• Hino Profia: Long-haul heavy tractors utilizing the E13C-T Euro 3/4/5 platform.
• Industrial Power: Specialized E13C generator sets and vocational chassis.
• Engine Series: Hino E13C, E13C-T, E13C-UY, E13C-VV 12.9L Turbocharged Diesel.
• Hino OEM Numbers: 24100-4223, S1760-E0040, 241004223, S1760E0040
• IHI Cartridge/Assembly Codes: VA520077, VE520040, VD520040, VC520040, VB520040, VA520040, VF520038, VE520038, VD520038, VC520038, VB520038, VA520038, VB520030, VA520030, VI520015, VH520015, VG520015, VF520015, VE520015, VD520015, VC520015, VB520015, VA520015

FAQs

Q1: Is replacing just the CHRA (Cartridge) enough to fix my turbo?

If your turbo housings (compressor and turbine) are free of cracks and the VGT mechanism (nozzle ring) moves freely, replacing the CHRA is a highly effective way to restore performance. It replaces all the internal rotating parts and bearings, which are the most common points of failure.

Q2: Does this CHRA fit all RHG8V models for the E13C engine?

The RHG8V series has many variations. This specific CHRA is designed to cross-reference with 24100-4223 and the IHI VA520015-VA520077 series. Please verify the number on your turbo's nameplate before ordering.

Q3: What is the most important step when installing a new Hino E13C CHRA?

Cleanliness and Lubrication. You must replace the Oil Feed Pipe and the Engine Oil/Filter. Before starting the engine, fill the oil inlet of the new CHRA with fresh engine oil and rotate the wheel by hand to prevent "dry start" bearing damage.

Q4: Do you offer a warranty for heavy-duty fleet operations?

Our RHG8V CHRAs are the preferred choice for fleet managers and professional workshops looking for OEM-level reliability without the OEM price tag.

Q5: Do you provide worldwide shipping? What is the delivery timeframe?

We ship globally via premium carriers like DHL, FedEx, and UPS, as well as sea freight for bulk orders. In-stock items are typically dispatched within 24–48 hours. Express delivery to North America and Europe usually takes 5–7 business days.

About Us

Fengcheng Zhongke Turbocharger Co., Ltd. is a leading high-tech factory specializing in the R&D, production, and global distribution of high-performance turbochargers. Based in Fengcheng—one of the world’s most renowned turbocharger manufacturing hubs—we have grown from a local workshop into a global supplier, serving heavy-duty, commercial, and passenger vehicle markets worldwide.

At Zhongke, we don't just "make" parts.we engineer reliability.

• Material Integrity: We exclusively use K18 Nickel-Alloy turbine wheels, capable of withstanding extreme exhaust temperatures (up to 950°C) without deformation.
• Dynamic Balancing: 100% of our turbochargers undergo high-speed dynamic balancing tests at 150,000+ RPM to guarantee zero vibration and extended bearing life.
• Certified Quality: Our production processes are certified under ISO 9001 and IATF 16949, the gold standards for the global automotive and heavy-machinery industries.

Manufacturing Prowess:Our facility is equipped with state-of-the-art production lines, including precision 5-Axis CNC machining centers, high-speed VSR (Vibration Sorting Rig) balancing machines, and advanced material testing labs.

Our Specialization:We maintain a vast inventory of over 3,500+ turbocharger models, with a focus on heavy-duty and construction machinery engines, including Cummins, Caterpillar, Komatsu, Scania, Kobelco, and Hitachi. Beyond heavy-duty machinery, we also provide a comprehensive range of turbochargers for passenger vehicles and light commercial vans. Our catalog covers over 1,000 applications for leading automotive brands including Nissan, Audi, BMW, Mercedes-Benz, Toyota, Honda, and Hyundai. Focused on optimizing fuel efficiency and restoring factory horsepower, our passenger car turbos are engineered with the same precision and K18 heat-resistant materials as our industrial line, ensuring reliable performance for daily commuting and high-speed driving alike.

Global Partnership & Support: Zhongke Turbo is more than just a manufacturer; we are your long-term technical partner. With nearly 30 years of export experience, we understand the logistics and technical requirements of the international market. We provide a warranty and dedicated technical support to help our partners succeed.

• Key Export Regions: North America, Europe, the Middle East, Africa, Latin America, and Southeast Asia.

Experience the difference of nearly 30 years of factory expertise. Contact us today for wholesale inquiries or technical consultations.
